เอฟเฟ็ก YAMAHA REV100 Digital Reverb Effect

เอฟเฟ็กเสียงร้อง REV100 ตอบสนองความถี่ที่ 20Hz to 20kHz ,มีโปรแกรม 99 โปรแกรม ,รองรับทั้งสัญญาณอะนาล็อค 2 AD in/ 2 DA out, 16 Bit/44.1KHz


฿20,000.00 ฿16,000.00



YAMAHA REV100 Digital Reverb Effect

เอฟเฟ็กเสียงร้อง REV100 ตอบสนองความถี่ที่ 20Hz to 20kHz ,มีโปรแกรม 99 โปรแกรม ,รองรับทั้งสัญญาณอะนาล็อค 2 AD in/ 2 DA out, 16 Bit/44.1KHz

Reverb is the essential effect for musical instruments, recording, and live sound. Delay and modulation run a close second and third. In fact, the quality of the effects you use has a major influence on the overall quality of your sound. If you’re looking for the kind of reverb, delay, and modulation effects that can give your sound a serious lift, take a good look at the Yamaha REV100 Digital Reverberator. It offers remarkably smooth, natural reverb sound as well as a range of outstanding studio-quality delay and modulation effects. It’s also super-simple to use, and surprisingly affordable for the quality and flexibility it offers. So affordable, in fact, that you could easily add several to your system for sensational processing power.

The Yamaha REV100: the easy way to add extraordinary ambiance to your sound.

REV100 Effect Categories


Programs 1 ~ 20: This category includes the essential reverb effects such as realistic hall, room, and plate reverb simulations.

Stereo Reverb

Programs 21 ~ 40: True stereo reverb effects that let you add ambiance to stereo signals without sacrificing the stereo image.

Gate Reverb

Programs 41 ~ 50: A range of “gated” reverb effects that add warmth and ambiance while maintaining a tight sound.


Programs 51 ~ 60: A selection of mono and stereo delay programs including straightforward one-shot repeats and complex bounce effects.


Programs 61 ~ 70: Combinations of delay and reverb that can add a little more life to your sound than delay or reverb alone.


Programs 71 ~ 99: Reverb combined with a range of modulation effects including flange, symphonic, chorus, and tremolo.



True Stereo Reverb

With common mono-in/stereo-out processors you can’t directly add reverb to a stereo signal. You could use two processor units, or mix the signal to mono and sacrifice the stereo image. The REV100 actually has stereo inputs and outputs, and a range of true stereo reverb programs that offer realistic ambience without destroying your stereo image. The REV100 will also function in the standard mono-in/stereo-out mode if you don’t need stereo processing.



Superior Sound Quality

The quality of your effect sound is just as important as the original sound itself. The REV100 offers CD-quality sound with 16-bit A/D and D/A converters and a 44.1 kHz sampling rate. The result is full 20 Hz to 20 kHz frequency response with exceptionally low noise and distortion, so your effects are totally clean and natural.



Advanced MIDI Features

If you’ll be using the REV100 in a MIDI music system, it offers some features that can make operation extra convenient. You can select effect programs via MIDI rather than the panel controls. This can be handy when you want to automatically select different effects for different patches on a synthesizer, for example. You can also use MIDI control change commands to actually change effect parameters, so you can vary the effect sound in real time while playing.



Other Important Features

Compact “1U” rack-mount dimensions.

Easy-to-read 2-digit LED display.

Peak LEDs make it easy to set the optimum input level.



Frequency Response 20 Hz ~ 20 kHz
Dynamic Range 80 dB (typical)
Distortion less than 0.1% (1 kHz, max.



Number of Channels 2 (phone jack)
Nominal Level –10 dB
Impedance 20 kΩ (STEREO)

10 kΩ (L-MONO)


Number of Channels 2 (phone jack)
Nominal Level –10 dB
Impedance 2 kΩ (STEREO)

1 kΩ (L-MONO)


AD Conversion 16 bit
DA Conversion 16 bit
Sampling Frequency 44.1 kHz
