ดิจิตอลมิกเซอร์ YAMAHA DM7 120-channel Digital Mixer
มิกเซอร์ดิจิตอล YAMAHA DM7 120-channel, Dual-bay Digital Mixer with 32 Mic Preamps, 28 Motorized Faders, 2 x 12″ Touchscreens, 1 x 7″ Touchscreen, 18-in/18-out Audio Interface, 144-in/144-out Dante Interface, and AI Assist
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…
฿1,350,000.00
Description
YAMAHA DM7 120-channel Digital Mixer
มิกเซอร์ดิจิตอล YAMAHA DM7 120-channel, Dual-bay Digital Mixer with 32 Mic Preamps, 28 Motorized Faders, 2 x 12″ Touchscreens, 1 x 7″ Touchscreen, 18-in/18-out Audio Interface, 144-in/144-out Dante Interface, and AI Assist
The DM7 is a cutting-edge, Dante-enabled 120-channel dual bay digital console designed for professional use. The DM7 is capable of 96kHz sample rates, boasts 28 faders, and provides dual 12″ high-resolution multi-touch screens supplemented by an additional 7″ screen, ensuring optimal visual feedback and intuitive control.
It incorporates an 18×18 audio interface, seamlessly integrating with Yamaha’s VST RACK to expand the console’s versatility.
Featuring a convenient DAW remote function, an internal dual power supply, and AI assist functions, the DM7 stands out with a unique combination of advanced capabilities, an ideal choice for a diverse range of professional applications, including live sound, theatrical productions, broadcast environments, and corporate AV.
Features:
- Built upon the innovative features and industry-leading sound of Yamaha’s Rivage PM series
- Packs 120 mixable channels into a dual-bay, 28-fader digital mixer
- 2 x 12-inch touchscreens, 1 x 7-inch touchscreen, and all-purpose touch-and-turn knobs provide easy operation and navigation
- Capable of sampling rates as high as 96kHz
- 48 mixes, 12 matrixes, 2 stereo buses, and 2 cue mixes
- 32 excellent-sounding mic preamps and 16 convenient analog outputs
- Excellent built-in DSP effects
- 64 assignable premium processing slots, 16 assignable Yamaha FX slots, and 4 assignable inserts per channel
- 144 x 144 Dante interface supplies loads of room for expansion
- 18 x 18 USB audio interface that works with Yamaha’s VST Rack
- DAW remote mode with transport control
- AI assist features seamlessly adapt its functions to your preferences and workflow
- Split mode assists a single engineer performing more than one task
- Internal dual power supply
Specifications
| Type | Digital Mixer |
| Channels | 120 |
| Inputs – Mic Preamps | 32 x XLR |
| Phantom Power | 32 Channels |
| Outputs – Main | 16 x XLR (main) |
| Inputs – Digital | 2 x XLR (AES/EBU), 2 x RJ-45 (Dante) |
| Outputs – Digital | 2 x XLR (AES/EBU) |
| Busses/Groups | 48 mixes, 12 matrixes, 2 stereo buses, and 2 cue mixes |
| MIDI I/O | 1 x 15-pin DIN (GPI) |
| Data I/O | 2 x Locking Ethernet (Dante network), 1 x RJ-45 (control) |
| Headphones | 1 x 1/4″ |
| USB | 1 x Type C |
| Computer Connectivity | USB (18 x 18), Ethernet |
| I/O Expansion Slots | 1 x Slots Available |
| Word Clock | 2 x BNC (in/out) |
| Faders | 28 x Motorized |
| A/D Resolution | Up to 24-bit/96kHz |
| Effects | Yes |
| Signal Processing | 64 Assignable Processing Slots, 16 Assignable FX Slots, 4 x Inserts per Channel |
| Features | A.I. Mix Assistant |
| Transport Controls | Yes |
| DAW Control | Yes |
| Screen | 2 x 12″ touchscreen, 7″ touchscreen |
| Software | DM7 Editor, DM7 StageMix, Console File Converter, MonitorMix, ProVisionaire Control/Touch |
| Power Source | 2 x Standard IEC AC Cable (redundant power supply) |
| Height | 12.75″ |
| Depth | 22.2″ |
| Width | 31.2″ |
| Weight | 50.7 lbs. |
