ลำโพง YAMAHA CHR10 เป็นลำโพงแบบ Passive 2 ทาง Passive Loudspeaker ขนาดดอกลำโพง 10 นิ้ว Woofer, เสียงแหลมขนาด 1.4 นิ้ว Compression Driver, 90 x 60° with Rotatable Horn, ทนกำลังขับ 175 วัตต์ RMS, 350 วัตต์ Program 700 วัตต์ Peak
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…เป็นราคาใบละ…
฿19,000.00 ฿16,720.00
ลำโพง YAMAHA CHR10 เป็นลำโพงแบบ Passive 2 ทาง Passive Loudspeaker ขนาดดอกลำโพง 10 นิ้ว Woofer, เสียงแหลมขนาด 1.4 นิ้ว Compression Driver, 90 x 60° with Rotatable Horn, ทนกำลังขับ 175 วัตต์ RMS, 350 วัตต์ Program 700 วัตต์ Peak
The CHR10 is a 2-way loudspeaker, equipped with a 10-inch woofer and a 1.4-inch HF driver, and perfect for use in fixed installations.
Combining carefully selected and customized transducers with the same high-grade plywood construction found on Yamaha’s high-end CZR Series, the CHR10 offers best-in-class sound quality and durability.

| Configuration | Passive 2-Way |
| Enclosure Type | Bass-Reflex Loudspeaker |
| Total Power Capacity | 175 W RMS 350 W Program 700 W Peak |
| Constant Voltage / Transformer Taps | None |
| System Impedance | 8 Ohms |
| HF Driver | 1 x 1.4″ / 35.6 mm Rotatable Horn Compression Driver with 1″ / 25 mm Throat |
| MF Driver | None |
| LF Driver | 1 x 10″ / 254 mm Woofer |
| LF Voice Coil | 2″ / 50.8 mm |
| Magnet | Ferrite |
| Frequency Range | 55 Hz to 20 kHz -10 dB |
| Maximum SPL | 122 dB |
| Coverage Angle | 90° H x 60° V (Rotatable Horn) |
| Speaker Sensitivity | 93 dB SPL |
| Audio I/O | 2 x speakON NL4 Speaker Input/Thru (Lockable) |
| Crossover | 2.5 kHz |
| Phase Adjustment | None |
| Mounting | 2 x M10 Fly Point (Top) 1 x M10 Fly Point (Rear) 1 x 1.4″ / 35 mm Pole Socket (Bottom) |
| Handles | 1 x Top |
| Construction Material | Perforated Metal Grille, Plywood, Polyurethane |
| Dimensions | 19.5 x 12 x 11.8″ / 495.3 x 304.8 x 299.7 mm |
| Weight | 30.2 lb / 13.7 kg |
