มิกเซอร์ BEHRINGER XENYX QX1832 USB Mixer

Name: มิกเซอร์ BEHRINGER XENYX QX1832 USB Mixer
Price: 13000.00 THB
Availability: InStock

มิกเซอร์ แบบอนาล็อค Behringer Xenyx QX1832USB เป็นมิกเซอร์แบบมีช่องสัญญานขาเข้า 18-Input 3/2-Bus Mixer with XENYX Mic Preamps & Compressors, KLARK TEKNIK Multi-FX Processor

ราคาไม่รวมภาษีมูลค่าเพิ่ม…..

฿13,000.00

สอบถามและสั่งซื้อสินค้า

Category: อนาล็อคมิกเซอร์ (Analog Mixer) Tag: BEHRINGER

Description

BEHRINGER XENYX QX1832 USB Mixer

The Behringer XENYX X1832USB-18-Input USB Audio Mixer with Effects is an 18-input audio mixer with an integrated USB computer audio interface. It enables you to mix together and shape the sound of multiple audio signals, and route the audio to several outputs. The mixer features six microphone preamps, “British”-style EQ, and six easy-to-use one-knob compressors.

It provides four mono channels and four stereo channels, making it suitable for small and medium-sized audio projects. There are three aux sends on every channel (which enable you to route individual channels to stage monitors or external effects), and three stereo aux returns. Every channel features a 3-band EQ with a swept mid, which can really help you make vocals and instruments stand out in a mix. The built-in USB interface allows for a bi-directional transfer of audio to and from your computer.

The built-in 24-bit dual-engine effects processor features 16 presets that include, reverb, chorus, flanger, delay, pitch shifter, and multi-effects. You can edit the parameters of every preset, and a tap tempo button is included to sync time-based effects. The six built-in compressors are designed to simplify the process of controlling dynamics in your mix. With a single knob you can dial in the amount of compression you need for any given sound. The six XENYX preamps offer 130 dB of dynamic range, and the 3-band “British”-style EQs allow you to finely tune your mix. The XENYX X1832USB is suitable for recording studios, video editing suites, live sound mixing, podcasting and more.

Features:

Premium ultra-low noise, high headroom mixer
6 state-of-the-art, phantom-powered XENYX Mic Preamps comparable to stand-alone boutique preamps
6 studio-grade compressors with super-easy “one-knob” functionality and control LED for professional vocal and instrumental sound
Ultra-high quality KLARK TEKNIK FX processor with LCD display, dual-parameters, Tap function and storable user parameter settings
“Wireless-ready” for high-quality BEHRINGER digital wireless system (not included)
Built-in stereo USB/Audio Interface to connect directly to your computer. Free audio recording, editing and podcasting software plus 150 instrument/effect plug-ins downloadable at behringer.com
Neo-classic “British” 3-band EQs with semi-parametric mid band for warm and musical sound
9-band stereo graphic EQ allows precise frequency correction of monitor or main mixes
Revolutionary FBQ Feedback Detection System instantly reveals critical frequencies
Breathtaking XPQ 3D stereo surround effect for more vitality and enhanced stereo image Voice Canceller function for easy-to-use sing-along applications
Channel inserts on each mono channel for flexible connection of outboard equipment
3 aux sends per channel: 1 pre fader for monitoring, 1 pre/post fader switchable for monitoring/FX applications, 1 post fader (for internal FX or as external send)
Clip LEDs, mute, main mix and subgroup routing switches, solo and PFL functions on all channels
2 subgroups with separate outputs for added routing flexibility and 2 multi-functional stereo aux returns with flexible routing
Balanced main mix outputs with gold-plated XLR connectors, headphone/control room output and stereo rec outputs
Long-wearing 60-mm logarithmic-taper faders and sealed rotary controls
“Planet Earth” switching power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Dimensions and Weight in Packaging
Shipping Weight: 14 lbs
Shipping Dimensions: 21 x 18 x 6 in

Specifications

Total # Of Inputs	18 inputs
Mic/Line Inputs	6 x XLR microphone inputs 8 x 1/4″ TRS line-level inputs
Stereo Line Inputs	4 x 1/4″ TRS left & right paired inputs
AUX Sends	3
AUX Returns	3 stereo returns
Inserts	4
BUS (Group) Outputs	2 sub groups
2 Trk Master I/O	2 x balanced XLR outputs 2 x 1/4″ TRS outputs
ALT I/O	2 x 1/4″ TRS sub outputs stereo RCA 2-track outputs
Monitor Outputs	2 x 1/4″ TRS control room outputs 1 x 1/4″ stereo headphone output
EQ Section	3-Band EQ with mid sweep on every channel
Graphic EQ	9-Band stereo graphic EQ
Solo/Mute	Mute and solo buttons on every channel
Channel Level Control	60 mm faders
Trim/Gain Control	Yes
Phantom Power	+48 V phantom
Metering	12-segment stereo LED meters Clip LEDs on every channel
Microphone Inputs
Type	XLR, electronically balanced, discrete input circuit
Mic Input Noise (E.I.N.)	20 to 20,000 Hz At 0 Ω source resistance: -134 dB/135.7 dB A-weighted At 50 Ω source resistance: -134 dB/133.3 dB A-weighted At 150 Ω source resistance: -129 dB/130.5 dB A-weighted
Frequency Response	Preamp: < 10 to 150,000 Hz (-1 dB) < 10 to 200,000 Hz (-3 dB) Mic Input to Main Output: <10 to 90,000 Hz (+0 dB / -1 dB) <10 to 160,000 Hz (+0 db / -3 dB)
Dynamic Range	Not specified by the manufacturer
Gain Range	10 to 60 dB
Maximum Input Level	+12 dBu at +10 dB Gain
Impedance	Approximately 2.6 kΩ balanced
Signal-to-Noise Ratio	110 dB A-weighted (0 dBu In @ +22 dB gain)
Total Harmonic Distortion (THD)	0.005% / 0.004% A-weighted
Line Input
Type	1/4″ TRS connector, electronically balanced
Impedance	Approximately 20 kΩ 10 kΩ unbalanced
Gain Range	-10 to +40 dB
Maximum Input Level	30 dBu
Crosstalk	Main fader closed: 90 dB Channel muted: 89 dB Channel fader closed: 89 dB
Stereo Input
Type	1/4″ TRS connector, electronically balanced
Impedance	Approximately 20 kΩ
Maximum Input Level	22 dBu
EQ Type Mono Channels	Low: 80 Hz, ± 15 dB Mid: 100 to 8,000 Hz, ± 15 dB High: 12,000 Hz, ± 15 dB
EQ Type Stereo Channels	Low: 80 Hz, ± 15 dB Low Mid: 500 Hz, ± 15 dB Mid: 3,000 Hz, ± 15 dB High: 12,000 Hz, ± 15 dB
AUX Section
AUX Sends	Type: 1/4″ TS connector, unbalanced Impedance: Approximately 120 Ω Maximum Output Level: 22 dBu
AUX Returns	Type: 1/4″ TRS connector, electronically balanced Impedance: Approximately 20 kΩ balanced, 10 kΩ unbalanced Maximum Input Level: 22 dBu
Main Outputs	Type: XLR, electronically balanced and 1/4″ TRS balanced Impedance: Approximately 240 Ω symmetrical, 120 Ω unbalanced Maximum Output Level: 28 dBu
Control Room Outputs	Type: 1/4″ TS unbalanced Impedance: Approximately 120 Ω Maximum Output Level: 22 dBu
Headphone Outputs	Type: 1/4″ TRS connector, unbalanced Maximum Output Level: 19 dBu at 150 Ω (+25 dBm)
DSP	Converter: 24-bit Sigma-Delta, 64/128-times oversampling Sampling Rate: 40 kHz
USB	Audio: Stereo In/Out Connector: Type B Converter: 16-bit Sample Rate: 48 kHz
Noise	Main mix at -∞ with channel fader at -∞: -101 dB Main mix at 0 dB with channel fader at -∞: -93 dB Main mix at 0 dB with channel fader at 0 dB: -81 dB
Power Supply
Mains	100 to 240 V, 50/60 Hz
Power Consumption	50 W
Fuse	100 to 240 V 1.6 A H 250 V
Connection	Standard IEC receptacle
Dimensions (H x W x D)	3.54 x 13.98 x 16.92″ (90 x 355 x 430 mm)
Weight	10.9 lb (4.94 kg)
