ตู้ลำโพง BMB CSP-610 Passive Two-Way loudspeaker 10″

฿24,500.00

ตู้ลำโพง BMB CSP-610 เป็นตู้ลำโพงแบบ Passive Two-Way loudspeaker Bass Reflex , ประกอบด้วยดอกลำโพง Woofer ขนาด 10″ ลำโพง Tweeter 1″ ทนกำลังขับ Continuous 300W, Program 600W, Peak 1200W, Impedance 8 Ohms, for KTV, Bar, Club, Restaurant

ราคาไม่รวมภาษีมูลค่าเพิ่ม…..เป็นราคาใบละ….

แชร์สินค้านี้: Facebook X LINE

Description

BMB CSP-610 Passive Two-Way loudspeaker 10″ 300W

ตู้ลำโพง BMB CSP-610 เป็นตู้ลำโพงแบบ Passive Two-Way loudspeaker Bass Reflex , ประกอบด้วยดอกลำโพง Woofer ขนาด 10″ ลำโพง Tweeter 1″ ทนกำลังขับ Continuous 300W, Program 600W, Peak 1200W, Impedance 8 Ohms, for KTV, Bar, Club, Restaurant, Various Scene

The BMB CSP-610 is a 2-way speaker with a 10-inch main speaker, a rated input of 300 watts, and a maximum input power of 1200 watts. It has an impedance of 8 ohms, a horizontal and vertical dispersion angle of 90 degrees, a polyswitch breaker for high-frequency protection, SPK4 x 2 connectors, a frequency response of 62 – 20,000 Hz

Cabinet made of high quality birch plywood assembled by box joint. The tough structure keeps outputting powerful sound stably. Clear high frequency sound by fine-tuned diaphragmA new type of vocal and music mixing style. Not only for KTV, but also for Bar, Club, Restaurant, various scene.

Features :

  • 2-Way 2-Speakers Bass-Reflex Speaker System (Single)
  • 10″ 1200W Max at 8 Ohms
  • Rotatable BMB Logo Plate make it possible to set up the speakers anywhere

Specifications

System Type Two-Way loudspeaker, bass reflex
Frequency Range(-10dB) *1 62Hz~20kHz
Frequency Response(±3dB) *1 107Hz~20kHz
Sound Pressure Level *2 94dB
Impedance 8Ω
Max Sound Pressure Level *3 119dB(Peak 125dB)
Power Capacity Continuous 300W, Program 600W, Peak 1200W
Dimensions (W)319×(H)530×(D)357mm
(12.6″×20.9″×14.1″)
Shipping Dimensions (W)425×(H)635×(D)460mm
(16.7″×25.0″×18.1″)
Net Weight 16.5kg(36.4lbs)
Shipping Weight 19.5kg(43.0lbs)
Input Connectors Speaker Connector(4P)×2
Pole Mount Cap Φ36mm(1.4″), Depth 75mm(3.0″)
Speaker unit LF Unit:250mm(10.0″) Cone, 65mm(2.6″) Voice Coil×1
HF Unit:25mm(1.0″) Throat, 34.4(1.3″)mm Voice Coil× 1
Enclosure Construction 15mm(0.6″) Plywood
Accessories Owners manual
Registration card
*1 Full space (4π) conditions
*2 1w1m on-axis, swept-sine in anechoic environment
*3 Calculated

Downloads

ดาวน์โหลด Data Sheet CSP-610
