เครื่องอัดเสียงพกพา Zoom F4 Multi-Track Field Recorder

เครื่องบันทึกเสียงดิจิตอลพร้อมไมโครโฟน Zoom F4, Records 6 Inputs & Stereo Mix, 4 x High-Gain, Low-Noise Mic Preamps, Ambisonics, WAV & MP3 Formats, Compatible with Zoom Mic Capsules, Flexible Powering Options, Dual SD Card / USB Interface Recording, AutoMix Software Reduces Mix Noise, Precision Time Code Reader/Generator

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม……

฿20,400.00

สอบถามและสั่งซื้อสินค้า

Description

Zoom F4 6-Input / 8-Track Multi-Track Field Recorder

เครื่องบันทึกเสียงดิจิตอลพร้อมไมโครโฟน Zoom F4, Records 6 Inputs & Stereo Mix, 4 x High-Gain, Low-Noise Mic Preamps, Ambisonics, WAV & MP3 Formats, Compatible with Zoom Mic Capsules, Flexible Powering Options, Dual SD Card / USB Interface Recording, AutoMix Software Reduces Mix Noise, Precision Time Code Reader/Generator

Zoom F4, a sound bag–friendly, multi-track field recorder with look-ahead limiters for distortion-free 24-bit audio, and up to 6-input / 8-track recording for filmmaking and video content creation on set and in the field. Like other F-Series recorders such as the F6 and F8n, you can slide it in a sound bag, sling it over your shoulder, or mount it to a camera; the F4 packs quantity and quality into a rugged frame that’s more than ready for filmmaking, production/location sound mixing, sound effects recording, and electronic news gathering (ENG).

From the large, informative display and user-friendly controls to the flexible powering options and precision time code functionality, the F4 is properly equipped to please novices and demanding veterans alike. Whether you need long-duration stereo recording for an interview, redundant capture of multi-mic setups for a video shoot, or Ambisonics sound files for virtual reality and 360-audio projects, the F4 has the modes, resolutions, and media support to handle your crucial audio tasks.

Plus, its operational versatility ensures that the F4 will always enhance your workflow, be it simple, complex, or always changing. You can feel confident using it as your main recorder, a USB audio interface for your dedicated computer rig, or a backup unit for added safety. Since it supports dual SD card recording, 2-channel safety recording, and 6-second pre-recording, you can stop worrying about losing takes.

Features:

  • Indie Filmmaking, Video Content Creation
  • Look-Ahead Limiters Prevent Clipping
  • 4 x High-Gain, Low-Noise Mic Preamps
  • Records 6 Inputs & Stereo Mix
  • Ambisonics, WAV & MP3 Formats
  • Compatible with Zoom Mic Capsules
  • Flexible Powering Options
  • Dual SD Card / USB Interface Recording
  • AutoMix Software Reduces Mix Noise
  • Precision Time Code Reader/Generator

Specifications

Portable Recorder
Number of Tracks WAV:
8 (6 Inputs + Stereo Mix)
MP3:
2
Max Sample Rate/Resolution 192 kHz / 24-Bit
Built-In Speaker No
Display Monochrome LCD (Backlit)
Memory Card Support SD (16 MB to 2 GB)
SDHC (4 to 32 GB)
SDXC (64 to 512 GB)
Internal Storage None
Recording
Audio File Formats BWF, ID3v1, MP3, WAV, iXML
Sample Rates WAV:
44.1 / 47.952 / 48 / 48.048 / 88.2 / 96 / 192 kHz
MP3:
44.1 / 48 kHz
Bit Depth 16/24-Bit
Bit Rates 128 to 320 kb/s
Signal Processing Limiter, Low-Cut Filter
Timecode Yes
Frame Rates Supported 23.976 / 24 / 25 / 29.97 / 29.97 DF / 30 / 30 DF
Clock Accuracy ±0.2 ppm
Recording Time WAV 48 kHz/24-Bit:
57.8 Mins per GB (Stereo)
WAV 192 kHz/24-Bit:
14.4 Mins per GB (Stereo)
Connectivity
Analog I/O 1 x Proprietary Mic Capsule Input
4 x Combo XLR-1/4″ Female Line/Mic Input (Lockable)
1 x 1/8″ / 3.5 mm TRS Female Unbalanced Line Input
2 x XLR 3-Pin Male Balanced Line Output
1 x 1/8″ / 3.5 mm TRS Female Unbalanced Aux Output
1 x 1/4″ TRS Female Unbalanced Headphone Output
Digital I/O 1 x BNC Timecode Input
1 x BNC Timecode Output
Phantom Power +24 / 48 V (Selectable on Individual Inputs)
Phantom Power Current ≤10 mA per Channel
Host Connection 1 x Mini-USB (USB 2.0)
Performance
Frequency Response 10 Hz to 80 kHz +0.5/-1 dB (At 192 kHz)
Gain Range Mic Inputs:
+10 to +75 dB
Line Inputs:
-10 to +55 dB
1/8″ Inputs:
-10 dBV / +4 dBu
Max Input Level Mic Inputs:
+14 dBu (Limiter On, at 0 dBFS)
Line Inputs:
+24 dBu (Limiter On, at 0 dBFS)
1/8″ Inputs:
+24 dBu
Max Output Level Line Outputs:
+10 dBV
Headphone Output Power 100 mW per Channel into 32 Ohms
Dynamic Range A/D Converters:
120 dBA
D/A Converters:
106 dBA
Impedance BNC Inputs:
≥4.3 kOhms
BNC Outputs:
≤50 Ohms
Mic Inputs:
≥3 kOhms
Line Inputs:
≥22 kOhms
Aux Inputs:
≥10 kOhms
Line Outputs:
≤150 Ohms
Aux Outputs:
≤1 kOhms
Headphone Outputs:
≤15 Ohms
EIN ≤-127 dBu (A-Weighted)
Power
Power Options Batteries or AC/DC Power Adapter
Battery Type 8 x AA (Not Included)
Approximate Battery Life 48 kHz/16-Bit:
9.5 Hours (Alkaline, 2 Channels, without Headphones)
11.5 Hours (NiMH, 2 Channels, without Headphones)
17.5 Hours (Lithium, 2 Channels, without Headphones)
48 kHz/24-Bit:
9 Hours (Alkaline, All Channels, with Headphones)
10.5 Hours (NiMH, All Channels, with Headphones)
16.5 Hours (Lithium, All Channels, with Headphones)
192 kHz/24-Bit:
2 Hours (Alkaline, All Channels, Backlit Display, Phantom On)
3.5 Hours (NiMH, All Channels, Backlit Display, Phantom On)
6 Hours (Lithium, All Channels, Backlit Display, Phantom On)
AC/DC Power Adapter 12 VDC at 2 A (Included)
Physical
Mounting Options 1/4″-20 Female
Dimensions 7.0 x 5.5 x 2.1″ / 177.8 x 139.7 x 53.3 mm
Weight 2.3 lb / 1.0 kg
Packaging Info
Package Weight 4.865 lb
Box Dimensions (LxWxH) 11.7 x 10.4 x 4.9″
