เพาเวอร์มิกเซอร์ MACKIE PPM1008 Power Mixer

เครื่องผสมสัญญาณเสียงแบบมีกำลังขยายในตัว MACKIE PPM1008 มีกำลังขับข้างละ 800 วัตต์ peak, 8-input, 3-Band EQ with Sweep, มาพร้อมกับ Compressors และ เอ็ฟเฟ็คร้องในตัว

ราคาไม่รวมภาษีมูลค่าเพิ่ม

฿46,900.00 ฿46,500.00

สอบถามและสั่งซื้อสินค้า

Description

MACKIE PPM1008 8-Channel Professional Powered Mixer (1600W)

เครื่องผสมสัญญาณเสียงแบบมีกำลังขยายในตัว MACKIE PPM1008 มีกำลังขับข้างละ 800 วัตต์ peak, 8-input, 3-Band EQ with Sweep, มาพร้อมกับ Compressors และ เอ็ฟเฟ็คร้องในตัว

The Mackie PPM1008 8-Channel Professional Powered Mixer features two built-in amplifiers that deliver a powerful 1600W (peak) to passive loud speakers. The mixer is a perfect match with Mackie passive loud speakers such as the C300 or S215 models.

A total of 8-channels is comprised of 4 mono line, 2 line / DI switchable, and 2 stereo channels. The first four channels feature XLR microphone inputs with phantom power, and channels 5 and 6 feature DI instrument inputs for direct connection of guitars.

Built-in compression dials are featured on channels 1 through 4 for easy on-touch compression setting. The Running Man 32-bit effects processor delivers “gig ready” usable effects presets that include plate reverb, room reverb presets, chorus settings and delays.

A full 3-band EQ section with mid-range sweep is featured on all mono inputs and two 9-band graphic EQ sections provide additional frequency contouring on output. The PPM1008 is designed for rigorous road use with built-in handles, rounded front chassis and ABS construction. The PPM1008 features the routing, features, sound quality, power and ruggedness expected for sound reinforcement on-the-go.

Features:

  • 800+800W Peak
  • 8-Channels
  • 32-Bit “Gig Ready” Effects
  • Built-In Compression
  • Built-In Instrument Inputs
  • Ultra Lightweight
  • 3-Band EQ with Sweep
  • Dual 9-Band Graphic EQ

Specifications

Power Rating 800+800W Peak
Mic/Line Inputs 3-pin XLR Microphone x8
1/4″ Phone Mono Line x4
L/R Stereo 1/4″ Phone Line x2
L/R Stereo RCA Phono Line x2
1/4″ Phone Mono Line/Instrument x2
Mains Inputs Unbalanced 1/4″ Phone A/B x2
In-Line Inputs/Returns No
Aux Sends MON1 Send – 1/4″ Phone
FX/MON2 Send – 1/4″ Phone
Aux Returns No
Inserts 1/4″ TRS Phone
All Mono and Instrument / Line Inputs
BUS (Group) Outputs MAIN Left/Right – L/R Stereo 1/4″ Phone
Main Output Speaker Outputs – A/B Speakon and 1/4″ Phone Connectors
Tape I/O L/R RCA Phono
Monitor Outputs MON1 Send – 1/4″ Phone
FX/MON2 Send – 1/4″ Phone
EQ Section Channel EQ
High Shelving: +/- 15dB @ 12kHz
Mid Peak Sweep (Mono chs): +/- 15dB
Mid Sweep Range: 100Hz to 8kHz
Hi Mid Peaking (Stereo chs): +/- 15dB @ 2.5kHz
Lo Mid Peaking (Stereo chs): +/- 15dB @ 400kHz
Low Shelving: +/- 15dB @ 80Hz
9-Band Graphic EQ
Main and Monitor 1: +/- 15dB @ 63, 125, 250, 500, 1k, 2k, 4k, 8k and 16kHz
Solo/Mute No
Channel Level Control Rotating Pot Controls
Trim/Gain Control Rotating Pot Controls
Phantom Power +48V
Metering Stereo Peak LEDs
Frequency Response Mic Mono Inputs: < 10Hz to 80kHz
Line Mono Inputs: < 10Hz to 40kHz
Line Stereo Inputs: < 10Hz to 75kHz
Signal-to-Noise Ratio -128dBu
Total Harmonic Distortion (THD) Mic Mono: < 0.007% High Gain
Mic Mono: < 0.005% Low Gain
Line Mono: < 0.005% Low Gain
Line Stereo: < 0.01% at Main Out
Power Supply 120VAC 50/60Hz
680W
Dimensions (HxWxD) 12.3 x 19.3 x 11.4″ (314 x 490 x 290mm)
Weight 24.5 lb (11.1kg)
