ไมโครโฟน JTS NX9 Instrument Microphone
ไมค์จ่อเครื่องดนตรี JTS NX9 ชนิดคอนเดนเซอร์ รูปแบบการรับเสียง Cardioid Impedance 400Ω เหมาะสำหรับ overheads, hi-hat, acoustic guitar and other instruments
ราคาไม่รวมภาษีมูลค่าเพิ่ม
฿3,200.00 ฿2,560.00
Description
JTS NX9 Instrument Microphone
ไมค์จ่อเครื่องดนตรี JTS NX9 ชนิดคอนเดนเซอร์ รูปแบบการรับเสียง Cardioid Impedance 400Ω เหมาะสำหรับ overheads, hi-hat, acoustic guitar and other instruments
The NX-9 is innovated for overheads, hi-hat, acoustic guitar and other instruments. The NX-9 provides extended frequency response and enlarged dynamic range. It delivers smooth and transparent reproduction.
Features:
- Type: Electret condenser
- Frequency Response: 60 to 18,000Hz
- Polar Pattern: Cardioid, rotationally symmetrical about microphone axis, uniform with frequency
- Output Level (at 1,000Hz): Open circuit voltage: -70dB*(0.32mV)*0dB=1V/µ bar
- Impedance: 400 30% (at 1,000 Hz)
- Phasing: Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
- Connector: Three-pin professional audio connector (male XLR type)
- Case: Metallic enamel-painted die cast metal with hardened, matte-finished steel grille
- Net Weight: 230 grams (8.1 oz)
- Touch Noise: Super low
- Power Supply: 9-52V phantom power or battery 1.5V AA
Specifications
| NX-9 | |
| Type | Electret Condenser |
| Frequency Response | 60~18,000 Hz |
| Polar Pattern | Cardioid,rotationally symmetrical about microphone axis, uniform with frequency |
| Sensitivity(at 1,000Hz) | -70dB*(0.32mV)*0dB=1V/μbar |
| Output Impedance | 400Ω |
| Phasing | Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3 |
| Connector | Three-pin professional audio connector (male XLR type) |
| Case | Metallic enamel-painted die cast metal body with hardened, matte-finished steel grille |
| Net Weight | 230 grams (8.1 oz) |
| Touch Noise. | Super low |
| Power Supply | 9-52V phantom power or battery 1.5V AA |
Downloads
ดาวน์โหลด Data Sheet JTS Microphone
