ลำโพงกลางแจ้ง EV EKX15S AP Passive Speakers 15″

Original price was: ฿49,500.00.Current price is: ฿42,000.00.

Electro-Voice EKX15S AP เป็นลำโพงซับเบสกลางแจ้งแบบไม่มีกำลังขยาย ตู้ไม้ขนาดดอกลำโพง 15″ แบบ 2 ทาง full-range 400-watt ,continuous and 1600 watts peak power, delivering 133 dB peak SPL.

ราคาสินค้าเป็นราคาต่อใบ…และไม่รวมภาษีมูลค่าเพิ่ม

แชร์สินค้านี้: Facebook X LINE

Description

ลำโพงแบบไม่มีกำลังขยาย EV EKX15SAP 400W

Electro-Voice EKX15S AP เป็นลำโพงซับเบสกลางแจ้งแบบไม่มีกำลังขยาย ตู้ไม้ขนาดดอกลำโพง 15″ แบบ 2 ทาง full-range 400-watt ,continuous and 1600 watts peak power, delivering 133 dB peak SPL.

The Electro-Voice EKX-15S passive subwoofer is part of EV’s EKX series, which combines legendary EV sound quality and reliability — all in a compact package suitable for a wide range of sound reinforcement scenarios, including musicians/DJs and live/club/installed sound applications.

Inside the EKX-15S, EV-engineered components and the Signal Synchronized Transducers (SST) waveguide design work together to provide precise coverage and superior sound quality at high SPLs. EV’s award-winning industrial design — with robust wood enclosures and durable EVCoat finish — ensures that EKX speakers look as great as they sound.

Features:

  • 1600 W (peak), 133 dB peak SPL on the EKX-15S utilizing high sensitivity transducers designed and engineered by EV
  • Lightweight, compact 15-mm wood enclosure with internal bracing, and durable EVCoat finish
  • Large slot ports for low distortion and excellent bass extension
  •  Metal grille reinforcement bar
  • M20 threaded pole mount plate

Specifications

EV EKX15S AP Passive Speakers

Axial Sensitivity (SPL, 1 W @ 1 m) 95 dB
Maximum SPL 133 dB Maximum SPL is measured at 1 m using broadband pink noise at rated peak power rating
Nominal Impedance 8 Ω
Power Handling (Continuous / Peak) 400 W/1600 W
Frequency Response (-3 dB) 60 Hz – 100 Hz Half Space Measurement
Frequency Response (-10 dB) 40 Hz – 300 Hz Half Space Measurement
Recommended High-Pass Frequency 35 Hz
LF Transducer EVS-15C 381 mm (15 in)
Minimum Impedance 7.5 Ω
Connector Type Dual NL4
Enclosure Material 15 mm, plywood with EVCoat
Grill 18 AWG steel with powdercoat
Height 455 mm (17.91″)
Width 530 mm (20.87″)
Depth 551 mm (21.69″)
Weight Net 24.9 kg (54.9 lbs)
Shipping Weight 31.3 kg (69 lbs)

DATASHEET

ดาวน์โหลด Manual EV EKX15S AP

ดาวน์โหลด Data Sheet EV EKX15S AP

ดาวน์โหลด Brochure EV EKX15S AP
