เพาเวอร์มิกเซอร์ BEHRINGER Europower PMP2000D Powered Mixer
เครื่องผสมสัญญาณเสียงแบบมีกำลังขยายแบบทรงตั้ง BEHRINGER Europower PMP 2000D, 14-Channel Mixer 6-Mono and 4-Stereo มีกำลังขับ 2000 วัตต์ Built-In Class-D Amplifier, Stereo, Dual Mono, or Bridged Mono Modes
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…..
฿17,500.00
Description
BEHRINGER Europower PMP2000D Powered Mixer 14-Ch 2000W
เครื่องผสมสัญญาณเสียงแบบมีกำลังขยายแบบทรงตั้ง BEHRINGER Europower PMP 2000D, 14-Channel Mixer 6-Mono and 4-Stereo มีกำลังขับ 2000 วัตต์ Built-In Class-D Amplifier, Stereo, Dual Mono, or Bridged Mono Modes, Nine “Invisible” IMP Mic Preamps, KLARK TEKNIK FX
The PMP2000D from Behringer is a 14-channel powered mixer featuring 2000 watts of Class-D amplification well suited for small to medium sized clubs, boardrooms, or in houses of worship. Channels 1-6 feature IMP mic preamps that include switchable pads and a clip LED, as well as six 1/4″ Hi-Z/line level inputs, which allows for connectivity from a variety of sources. Channels 7-12 are configured as stereo pairs with stereo 1/4″ line inputs and three IMP mic preamps. Channels 13-14 feature unbalanced RCA inputs for stereo playback as well as stereo RCA outputs for recording to an external device. Additionally, a 1/8″ auxiliary input with level control allows you to connect an MP3 player or similar source.
Each channel features a musical 3-band EQ, level control, monitor send, and FX send. The master section includes a 24-bit KLARK TEKNIK effects processor with 25 presets, level control, and a tap-tempo button for time-based effects. The dual 9-band EQ allows you to dial in separate EQ settings for the monitor and master outputs allowing for the best sound possible to the front-of-house, while eliminating feedback from the monitors. The mixer also features a USB port that enables channels 1&2 to be directly compatible with Behringer’s UltraLink ULM series wireless microphone system. The PMP2000D ships with a power cord.
Features:
- Ultra-compact 2x 1000-Watt stereo powered mixer
- Class-D amplifier technology: enormous power and excellent sonic performance in a light weight package
- 9x “Invisible” IMP mic preamps with switchable +48 V phantom power for condenser microphones
- Ultra-high quality KLARK TEKNIK FX processor with 25 presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
- “Wireless-ready” for high-quality Behringer digital wireless system (not included)
- 14-channel mixer section features 6 mono and 4 stereo channels
- Musical 3-band EQ, switchable Pad and Clip LEDs on all mono channels
- Dual 9-band graphic EQs allow precise frequency correction of monitor and main outputs
- Selectable stereo (main L/R), double mono (main/monitor) or bridged mono amplifier operation mode
- Adjustable stereo Aux input for connecting external signal sources
- Internal switch-mode power supply, noise-free audio, superior transient response and very low power consumption
Specifications
| Type | 9x XLR, electronically balanced |
| Mic Input Noise (E.I.N.) | 20 Hz to 20 kHz At 0 Ohms Source Impedance: -108 dB / -110 dB A-weighted At 50 Ohms Source Impedance: -108 dB / -110 dB A-weighted At 150 Ohms Source Impedance: -106 dB / -107 dB A-weighted |
| Frequency Response | < 20 Hz to 22 kHz (-1 dB) < 20 Hz to 35 kHz (-3 dB) |
| Maximum Input Level | +13 dBu with PAD |
| Impedance | 1.5 kOhms, balanced |
| Signal-to-Noise Ratio (SNR) | 98 dB / 100 dB A-weighted (-15 dBu In @ +35 dB gain) |
| Distortion (THD) | 0.002%, A-weighted |
| Pad | -25 dB, channels 1-6 |
| Phantom Power | Switchable +48 V |
| Type | 4x 1/4″ / 6.35 mm TRS, balanced (channels 1-4) |
| Impedance | 1.8 MOhms balanced, 1 MOhm unbalanced |
| Max Input | + 22 dBu |
| Type | 2x 1/4″ / 6.35 mm TRS connector, channels 5-6 |
| Impedance | 20 kOhms balanced, 10 kOhms unbalanced |
| Maximum Input Level | + 22 dBu |
| Type | 6x 1/4″ / 6.35 mm TRS connector, balanced channels 7-12 |
| Impedance | 20 kOhms balanced, 10 kOhms unbalanced |
| Maximum Input Level | + 22 dBu |
| Line In | 2-Track / Line In: 2x RCA, unbalanced, channels 13-14 |
| Impedance | 20 kOhms unbalanced |
| Gain Range | – ∞ dB to + 20 dB |
| Maximum Input Level | + 22 dBu |
| Equalizer | Low: 60 Hz (± 15 dB) Mid: 700 Hz (± 15 dB) High: 6 kHz (± 15 dB) |
| Graphic EQ | Type: Analog 9-band equalizer |
| Frequency Range | 20 Hz to 20 kHz in 9 1-octave bands (ISO frequencies) |
| Bandwidth | 1 octave |
| Control Range | ± 12 dB |
| Low Cut Frequency | Type: 18 dB/oct, Butterworth, channels 1-6 Frequency: 100 Hz |
| Type | 1/8″ / 3.5 mm TRS connector, unbalanced |
| Impedance | 10 kOhms |
| Gain Range | – ∞ dB to +20 dB |
| Type | 2x RCA, unbalanced |
| Impedance | 2.4 kOhms |
| Maximum Output Level | + 9 dBu |
| USB | USB Dongle (Not Included): USB socket accepts signals from a maximum of two Behringer ULM microphones |
| Signal Indicator | LED: 2x green |
| Noise | Main Mix at – ∞, Channel Fader at – ∞: – 59 dBu / – 59 dBu A-weighted Main Mix at 0 dB, Channel Fader at – ∞: – 56 dBu / – 56 dBu A-weighted Main Mix at 0 dB, Channel Fader at 0 dB: – 56 dBu / – 56 dBu A-weighted |
| Maximum Output Power | Both Channels Driven 8 Ohms Per Channel: 500 W 4 Ohms Per Channel: 1000 W Bridged Mode 8 Ohms: 2000 W |
| Type | Speakon connector |
| Load Impedance | Left/Monitor: Minimum 4 Ohms Right/Mono: Minimum 4 Ohms Bridge: Minimum 8 Ohms |
| Display | 2-digit, 7-segment LED |
| Power | Mains voltage 120 VAC, 50/60 Hz Mains Connection: Standard IEC receptacle |
| Fuse | T 8 A H 250 V |
| Power Consumption | Power Consumption at 4 Ohms, 1/8 Rated Power: 180 W |
| Dimensions (H x W x D) | 10.9 x 17.9 x 9.8″ / 27.6 x 45.5 x 25.0 cm |
| Weight | 19.8 lb / 9.0 kg |
