Description
AUSTRALIAN-MONITOR AMH2400 Power Amplifier
เครื่องขยายเสียงกลางแจ้ง AUSTRALIAN-MONITOR AMH2400 2RU มีกำลังขับ 2×1200 วัตต์ 2 Ohms, 900วัตต์ 4 Ohms, 650 วัตต์ 8 Ohms, Class H operation
The AMH2400 is a 2RU class H stereo power amplifier delivering 2400W into mono, stereo or bridged outputs. The
AMH2400 features individual front panel volume control, level meter, clip and protection indicators.
The AMB series of power amplifiers have been specifically designed and built to offer Australian Monitor customers a reliable, outstanding value for money amplifier for applications that require high quality audio reproduction that
The AMH series power amplifiers give the audio contractor a reliable amplifier for applications that are price sensitive yet still require high quality sound reinforcement.
Features:
- 2400W Amplifier
- Mono, Stereo or Bridge Mode operation
- Class H operation
- 2 Ohm /4 Ohm or 8 Ohm Operation
- Balanced XLR input and thru output
- Limiter
- High or Low pass filter per channel
- 2 RU
- Fan cooled
Specifications
AUSTRALIAN-MONITOR AMH2400
| Model |
AMH2400 |
AMH3600 |
| Topology |
Class H |
Class H |
| Channels |
2 |
2 |
Power Output (per channel) Single Channel 2Ω
Single Channel 4Ω
Single Channel 8ΩMono 2Ω (Both Driven) Mono 4Ω (Both Driven) Mono 8Ω (Both Driven) Bridged 4ΩBridged 8Ω |
1600W 1000W 570W 1200W 900W 525W 2400W 1850W |
2300W 1400W 800W 1800W 1100W 700W 3600W 2200W |
| Frequency Response |
25Hz – 20kHz |
25Hz – 20kHz |
| Signal to Noise Ratio |
> 100 dBA |
> 100 dBA |
| THD+N. 4Ω, 8Ω. 1kHz |
< 0.06% |
< 0.06% |
| Input Connectors |
2 Female XLR, 2 Male XLR |
2 Female XLR, 2 Male XLR |
| Output Connectors |
4 Binding Post, 2 speakON |
4 Binding Post, 2 speakON |
| AC Input |
230Vac, 50-60Hz |
230Vac, 50-60Hz |
| Dimensions (W x D x H) |
483mm x 400mm x 88mm (19” x 15.75” x 3.5”) |
483mm x 400mm x 88mm (19” x 15.75” x 3.5”) |
| Shipping Dimensions (W x D x H) |
540mm x 532mm x 190mm (21.26” x 20.9” x 7.48”) |
540mm x 532mm x 190mm (21.26” x 20.9” x 7.48”) |
| Net Weight |
11.5kg (25.35 lbs) |
11.9Kg (26.23 lbs) |
| Shipping Weight |
13.6 kg (29.98 lbs) |
13.9Kg (30.64 lbs) |
| Mounting |
2 RU |
2 RU |
| Colour |
Black |
Black |
