มิกเซอร์ BEHRINGER EURORACK PRO RX1602 Mixer
เครื่องผสมสัญญาณเสียง แบบเข้าแร็ค Behringer EURORACK PRO RX1602, Professional Multi-Purpose 16-Input Ultra-Low Noise Line Mixer, Balance and Level Control and +4/-10 Switching Per Channel
ราคาไม่รวมภาษีมูลค่าเพิ่ม…..
฿5,200.00
Description
BEHRINGER EURORACK PRO RX1602
เครื่องผสมสัญญาณเสียง แบบเข้าแร็ค Behringer EURORACK PRO RX1602, Professional Multi-Purpose 16-Input Ultra-Low Noise Line Mixer, Balance and Level Control and +4/-10 Switching Per Channel
The Behringer EURORACK Pro RX1602 is a professional multipurpose 16-input ultralow-noise line mixer. It can be used as an extremely flexible keyboard and multipurpose submixer, multitrack monitoring mixer, level translator, or an FX return submixer. There are 16 balanced, high-headroom line inputs for individual stereo or mono use of each section.
Low-noise design assures the highest possible headroom and ultratransparent audio. Dedicated balance and level controls plus +4/-10 level selection per channel and monitor/FX send control per section with global master send control allow for flexible monitoring, recording, or effects applications.
Features:
- Extremely flexible multi-purpose sub-mixer, multi-track monitoring mixer and level translator
- 16 balanced high-headroom line inputs for individual stereo or mono use of each section
- Ultra-low noise ULN design, highest possible headroom, ultra-transparent audio
- Dedicated balance and level controls plus +4/-10 level selection per channel
- Monitor/FX Send control per section with global master send control for flexible monitoring, recording or effects applications
- Illuminated double-function “mute” button per section with additional “clip” indication provides comfortable input source/level information
- Monitor/FX signal assignable to phones output for added flexibility
- Highly accurate 2 x 7-segment LED level meters and individual level control for left and right main mix signal
- 1/4” TRS main mix outputs plus easily accessible headphones output on the front panel with dedicated level control
- High-quality detented rotary controls for long-term reliability
- Shielded toroidal power transformer for lowest noise interference
- High-quality component components and exceptionally rugged construction ensure long life
- Conceived and designed by BEHRINGER Germany
Specifications
| Total # Of Inputs | 16 – 1/4″ TRS Phone |
| Mic/Line Inputs | 16 – 1/4″ TRS Phone line level only, no mic inputs available |
| Stereo Line Inputs | 8 Channels with L/R paired inputs |
| In-Line Inputs/Returns | No |
| AUX Sends | Mon Out: 1/4″ Phone mono |
| AUX Returns | Use channel inputs for returning effects |
| Inserts | No |
| BUS (Group) Outputs | No |
| 2 Trk Master I/O | Main Out: L/R 1/4″ TRS Phone |
| ALT I/O | No |
| Monitor Outputs | Mon Out: 1/4″ Phone same as AUX Send output
Headphone: 1/4″ Stereo Phone |
| EQ Section | No |
| Solo/Mute | Mute provided on all input channels |
| Channel Level Control | Rotary controls (POTS) |
| Trim/Gain Control | Rotary controls (POTS) |
| Phantom Power | not applicable – no microphone inputs available |
| Metering | Stereo 7 Segment Peak LEDs
Mute / Clip LED on all channels |
| Frequency Response | 20Hz – 20kHz +/-0.2dB |
| Dynamic Range | not specified by manufacturer |
| Signal-to-Noise Ratio | < -97dB |
| Total Harmonic Distortion (THD) | 0.0025% @ +4dB input 1 kHz gain 1 |
| Power Supply | Voltage: USA/Canada 120 V~, 60Hz
Consumption: max. 14 W Fuse: T 630 mA H Mains Connection: Standard IEC |
